LV833760 Interlock Accessory Unit

Feature & Principle

It adopts pure mechanical linkage structure. It locks the drawout chassis in disconnected or test position, limits the breaker to close under specified state. It prevents wrong switching operation during maintenance, realizes safety interlock protection for low-voltage power distribution cabinet.

Specifications

Model: LV833760 Brand: Schneider Applicable series: MasterPact MTZ drawout type Function: Mechanical key interlock, anti-misoperation Mounting: Install on breaker drawout chassis Certification: CE, IEC60947

Components & Diagnostics

Lock body, linkage rod, key, mounting bracket, fasteners. Common faults: linkage stuck, lock failure, key can not turn, interlock misalignment.

Product Brief

LV833760 interlock accessory, Schneider low voltage spare widely used for industrial power distribution cabinet, factory main power cabinet MTZ air breaker safety transformation and maintenance.
