Magnescale LT80 Measurement Display Unit

Feature & Principle

It collects position signals from multiple digital displacement gauges, calculates measured values and outputs comparison judgment results. It has MAX/MIN/P-P measurement modes, comparator output and data storage function via USB, SD card and Ethernet. It can send measurement data to upper computer for SPC quality statistical analysis.

Specifications

Model: LT80 Brand: Magnescale Screen: 7-inch touch LCD Max connected axes: 32 axes Interface: USB, SD card, Ethernet, digital I/O Power supply: 24VDC Mounting: Panel mount Certification: CE

Components & Diagnostics

Touch LCD panel, main control board, signal input interface, status indicator, communication port. Common faults: touch unresponsive, gauge signal loss, Ethernet communication failure, screen no backlight, data saving error.

Product Brief

LT80 measurement display unit, Magnescale precision instrument spare widely used for auto parts, mold and machining workshop dimensional inspection station.
