Meggitt 0504KHSA4 Magnetic Speed Pickup Probe Unit

Feature & Principle

This passive reluctance sensor relies on electromagnetic induction. When gear teeth sweep the probe tip, it generates sine AC pulse signal, signal frequency corresponds to shaft rotational speed. The turbine control unit calculates speed value and executes overspeed trip interlock.

Specifications

Model: 0504KHSA4 Brand: Meggitt Type: Passive variable reluctance speed probe Output: Induced AC sine pulse Working temperature: -55 ~ +200 ℃ Structure: Hermetically sealed stainless steel housing Mounting: Threaded installation Certification: Turbine high reliability grade

Components & Diagnostics

Magnetic core, induction coil, stainless steel shell, integrated cable assembly. Common faults: coil open circuit, weak signal amplitude, intermittent signal dropout, probe tip abrasion, cable insulation damage.

Product Brief

0504KHSA4 speed probe, Meggitt high-reliability spare widely used for gas turbine shaft speed monitoring and overspeed protection loop.
