MODICON 110CPU61203 PLC Controller

Technical SpecificationsModel:110CPU61203 (CPU61203) Brand:MODICON Product Type:Micro Series Integrated PLC CPU Controller Power Supply:24V DC Mounting:Cabinet DIN rail mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.92kg Dimension:210mm115mm78mm Protection:IP20

System compatibility110CPU61203 belongs to MODICON Micro series integrated PLC controller. Compatible with Micro series expansion I/O modules, supporting RS232 and RS485 serial communication. It can connect with HMI, sensors and actuators, communicate with other MODICON Micro PLC units. Suitable for packaging machinery, small production line, general machine control system replacement as industrial spare part.

Function110CPU61203 is compact all-in-one programmable logic controller with onboard digital and analog I/O. It executes ladder logic program, collects digital and analog field signals and outputs control signals to actuators. It supports program storage, battery-backed data retention, high-speed counter and interrupt function, built-in analog input and output channels, fault self-diagnosis. Widely used for standalone machine automation control, serving as reliable PLC spare part.

InstallationCut off power before installation. Mount the 110CPU61203 controller on DIN rail inside electrical cabinet. Connect 24V DC power cable and field I/O wiring. Connect serial communication cable for programming. Download PLC program and complete I/O test before formal operation.

InterfaceRS232 programming port, RS485 communication port, digital I/O terminals, analog I/O terminals, status LED indicators for 110CPU61203 MODICON PLC controller.

FeatureMODICON 110CPU61203 Micro integrated PLC,CPU, power supply, digital and analog I/O integrated design,compact DIN rail installation,built-in high-speed counter,battery memory retention,rich serial communication,IP20 cabinet protection. This discontinued legacy industrial spare part used for old standalone machine control system maintenance and replacement.

DiagnosticController no power: check 24V DC input, fuse and power wiring for 110CPU61203. CPU run failure: check program error, battery status and memory fault. I/O signal abnormal: inspect field sensor wiring, actuator circuit and terminal contact. Communication failure: verify serial cable, station address and baud rate configuration. Fault alarm: read fault information via ProWORX programming software.

Product Brief110CPU61203 is MODICON Micro series integrated PLC controller with built-in digital and analog I/O. This compact all-in-one PLC is widely used for small machinery automation control, integrated analog channels for temperature and pressure acquisition, classic spare part for legacy equipment overhaul.

Disclaimer:All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
