MODICON 120-088-002 Encoder Feedback Module

Technical SpecificationsModel:120-088-002 Brand:MODICON Product Type:120 Series Servo Encoder Feedback Interface Module Signal Type:Differential encoder signal Backplane Power:5V DC supplied by rack backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.1kg Dimension:260mm140mm30mm Protection:IP20

System compatibility120-088-002 belongs to MODICON 120 series encoder feedback module. Compatible with MODICON 984 series CPU,MM series motion processor and MODICON servo motors. It can be installed in local rack or remote RIO rack. Suitable for machine tool,packaging machinery,textile equipment,automated assembly line servo position signal collection renovation and replacement as industrial spare part.

Function120-088-002 servo encoder feedback module. It receives differential pulse signals from servo motor encoder,convert pulse signal into digital position data and transmit to motion processor. It monitors encoder signal integrity,detect signal loss and wiring fault. Built-in channel signal monitoring and module self-diagnosis function. Widely used for servo closed-loop position feedback acquisition, serving as reliable encoder signal spare part.

InstallationCut off rack power and servo power before installation. Insert 120-088-002 module into MODICON backplane slot and lock the card. Check gold finger contact condition. Connect encoder feedback cables to module terminal block. Configure module address and encoder type,verify position reading and complete function test before formal operation.

InterfaceBackplane bus connector,encoder signal terminal block,signal status and fault LED indicators for 120-088-002 MODICON encoder feedback module.

FeatureMODICON 120-088-002 encoder feedback module,support differential encoder signal,signal loss detection,real-time LED status indication,standard single slot rack design,anti-interference design for industrial workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON multi-axis motion control system encoder signal acquisition maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for 120-088-002. Position reading abnormal: check encoder wiring,encoder damage and signal interference. Signal loss alarm: inspect cable breakage and loose terminal connector. Intermittent position jump: check cable shielding,grounding and electromagnetic interference. LED abnormal: verify module hardware damage and backplane power supply.

Product Brief120-088-002 is MODICON 120 series servo encoder feedback module. It collects encoder pulse signal for servo closed-loop position control,classic spare part for legacy MODICON industrial motion equipment overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
