MODICON MM-08MP-001 Motion Processor Module

Technical SpecificationsModel:MM-08MP-001 Brand:MODICON Product Type:MM Series 8-Axis Motion Control Processor Module Control Axis:8 servo axes Motion Function:Position, speed, torque, electronic cam, synchronization Backplane Power:5V DC supplied by rack backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.4kg Dimension:260mm140mm30mm Protection:IP20

System compatibilityMM-08MP-001 belongs to MODICON MM series motion processor module. Compatible with MODICON 984 series CPU,backplane and matching servo drive units. It works together with MODICON servo motors for multi-axis motion control. Suitable for packaging machinery,machine tool,textile equipment,automated assembly line multi-axis synchronization renovation and replacement as industrial spare part.

FunctionMM-08MP-001 8-axis motion processor module. It receives motion instructions from PLC CPU and independently executes multi-axis closed-loop motion control,realizes point-to-point positioning,interpolation,electronic cam and axis synchronous operation. It outputs pulse or analog command signals to servo drives and reads encoder feedback signals. Widely used for multi-axis high-precision motion control of automation equipment, serving as reliable motion control spare part.

InstallationCut off rack and servo power before installation. Insert MM-08MP-001 motion module into MODICON backplane slot and lock the card. Check gold finger contact condition. Connect command cable and encoder feedback cables to servo drives. Configure axis parameters,complete servo tuning and motion test before formal operation.

InterfaceBackplane bus connector,servo command output port,encoder feedback port,status and fault LED indicators for MM-08MP-001 MODICON motion processor module.

FeatureMODICON MM-08MP-001 8-axis motion processor,independent multi-axis motion calculation,rich motion instruction set,support electronic cam and synchronization function,standard single slot rack design,anti-interference design for industrial workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON multi-axis motion automation system maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for MM-08MP-001. Axis motion abnormal: check command cable,encoder wiring,axis parameter setting and servo enable signal. Synchronization error: inspect cam table configuration and mechanical load condition. Motion overrun alarm: check limit switch wiring and parameter soft limit setting. Module hardware fault: inspect backplane power supply and internal circuit damage.

Product BriefMM-08MP-001 is MODICON MM series 8-axis motion processor module. It executes multi-axis interpolation and synchronous motion control for servo system,classic spare part for legacy MODICON industrial motion control equipment overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
