MODICON AS-B352-001 Discrete Output Module

Technical Specifications

Model: AS-B352-001 Brand: MODICON(AEG/Schneider) Product Type: Series 300 8 Channel Discrete Digital Output Module Channels: 8 digital output channels Signal Type: 24VDC output Backplane Bus: Modicon 984 Series 300 backplane Mounting: Backplane rack slot mount Operating temperature: 0℃ ~ +60℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Weight: 0.85kg Dimension: 260mm140mm30mm Protection: IP20

System compatibility

AS-B352-001 belongs to MODICON Series 300 discrete output module. Compatible with MODICON 984 CPU and Series 300 rack backplane. It receives control commands from PLC to drive field 24VDC actuators. Suitable for chemical plants, water treatment, packaging machinery, conveyor systems legacy Modicon 984 PLC system renovation and replacement as industrial spare part.

Function

AS-B352-001 8-channel digital output module. It accepts on/off control commands sent by MODICON 984 CPU, switches 24VDC field circuit to control solenoid valves, contactors, indicator lights and auxiliary relays. Each channel has LED status indicator for on-site status check. Built-in short-circuit protection and hardware self-diagnosis function. Widely used for discrete on-off actuator control in legacy MODICON 984 automation system, serving as reliable digital output spare part.

Installation

Cut off rack power before installation. Insert AS-B352-001 module into MODICON Series 300 backplane slot and lock the card. Check gold finger contact condition. Connect field load wiring to terminal block. Configure I/O address mapping, test output action, verify load response before formal operation.

Interface

Backplane bus connector, field digital output terminal block, channel status and fault LED indicators for AS-B352-001 MODICON digital output module.

Feature

MODICON AS-B352-001 Series 300 output card, 8 independent 24VDC output points, per-channel LED indication, short-circuit protection, standard single-slot rack design, industrial anti-interference design. This discontinued legacy industrial spare part used for old MODICON 984 PLC digital output control maintenance and replacement.

Diagnostic

Module not recognized: check rack power supply, backplane contact and module insertion for AS-B352-001. No output action: inspect PLC program logic, backplane communication and load wiring. Short-circuit alarm: check field cable damage and actuator overload. Intermittent output dropout: verify loose terminal and electromagnetic interference. LED no illumination: confirm module power supply and program output state.

Product Brief

AS-B352-001 is AEG MODICON Series 300 8-channel 24VDC digital output module. It switches 24VDC field loads according to PLC logic commands for Modicon 984 automation system, classic spare part for legacy MODICON industrial automation equipment overhaul.
