MODICON ZAE105 Servo Gear Reducer

Technical SpecificationsModel:ZAE105 Brand:MODICON Product Type:Servo Helical Gear Reducer Gear Type:Helical gear Mounting:Flange mounting,direct coupled to servo motor Operating temperature:0℃ ~ +40℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:4.2kg Dimension:165mm120mm110mm Protection:IP65

System compatibilityZAE105 belongs to MODICON servo matching gear reducer. Compatible with MODICON A series servo motors and MODICON motion control system. Suitable for packaging machinery,automated assembly lines,textile equipment high precision positioning renovation and replacement as industrial spare part.

FunctionZAE105 servo helical gear reducer. It matches with MODICON servo motor,reduces output speed and increases torque for motion axis. It adopts helical gear structure to ensure smooth rotation and low backlash. It provides mechanical deceleration for linear or rotary positioning axis. Widely used as servo power transmission mechanical spare part for legacy MODICON motion control system.

InstallationCut off servo power before installation. Mount ZAE105 gearbox on servo motor flange,align shaft and tighten mounting bolts. Install output side to mechanical load. Check lubricating oil level and sealing before commissioning. Complete no-load running test before formal operation.

InterfaceServo motor flange interface,output shaft,oil filling/drain port for ZAE105 MODICON gear reducer.

FeatureMODICON ZAE105 helical servo reducer,low backlash,high torsional rigidity,compact flange structure,good sealing,shock resistance for industrial workshop environment. This discontinued legacy industrial spare part used for old MODICON servo motion system mechanical transmission maintenance and replacement.

DiagnosticAbnormal noise: check lubricating oil,gear wear and misalignment for ZAE105. Oil leakage: inspect oil seal aging and housing screw loose. Overheating: check overload operation and insufficient lubrication. Vibration alarm: verify shaft alignment and gear tooth damage.

Product BriefZAE105 is MODICON high precision helical servo gear reducer. It matches MODICON servo motor to realize speed reduction and torque amplification for motion positioning axis,classic spare part for legacy MODICON industrial motion equipment overhaul.
