NEMA 9-7/16 C-Face Flange Dimension Unit

Module Feature

9-7/16" is defined by NEMA MG1 industry standard. It is the C-face flange outside diameter for NEMA 184TC frame induction motors. This standard is adopted by all NEMA motor manufacturers including Baldor, Marathon, ABB, Leeson, Allen‑Bradley. It ensures mechanical interchangeability between motor, gear reducer and close-coupled pump. This entry is only mechanical dimension specification and contains no electrical components.

Working principle

Passive mechanical standard. Defines flange outer profile, bolt circle reference and mounting footprint. Guarantees accurate alignment for flange coupling assembly. No electronic parts.

Onboard components

Not applicable, pure dimensional reference.

LED indicators

No built-in LED indicators.

Hardware self-diagnosis

Use caliper to verify actual flange OD, inspect flatness, check surface machining defects.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:9-7/16 Brand:NEMA Standard (Non brand-specific) Device type:NEMA MG1 standard C-face flange dimension Size:9-7/16 inch = 239.7 mm Matched frame:184TC Function:Flange dimension reference for NEMA motor coupling Cooling:Not applicable Protection:Depends on complete motor assembly

Mechanical & Structure

Mounting:C-face flange mounting Protection class:Depends on complete motor assembly Housing:Depends on matched motor housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:NEMA MG1 standard compliant Status: Universal NEMA standard dimension for 184TC C-face motor flange

Installation

Follow strict safety procedure before handling. Select pump or gear reducer flange conforming to NEMA 9-7/16 dimension, ensure tolerance meets coupling assembly requirement.

Interface

C-face flange interface, flange bolt holes.

Diagnostic

Dimension out of tolerance:machining error, causes coupling misalignment, vibration and premature bearing failure.

Product Brief

NEMA standard 9-7/16 inch C-face flange dimension for NEMA 184TC frame motors, universal industry footprint, applies to all NEMA motor brands for pump and gearbox flange coupling.
