Omron NT296 Touch Panel HMI

Feature & Principle

It is Omron NT series industrial programmable touch terminal. It communicates with Omron C, CJ, CS series PLC via serial ports to realize data monitoring, parameter setting, alarm display and recipe management. It uses resistive touch screen, configured by NTST support software. Built-in lithium battery for data backup. This model has been discontinued, widely used for spare replacement of old packaging machines, textile machines and production line control cabinets.

Specifications

Model: NT296 Brand: Omron Series: NT Display: Monochrome / color TFT optional Touch type: Analog resistive touch Power supply: 24 VDC Communication: RS232, RS422 Front protection: IP65 Mounting: Panel flush mount Software: NTST Application: Packaging machine, textile equipment, legacy PLC automation system Certification: CE, UL

Components & Diagnostics

Display assembly, resistive touch glass, main control PCB, communication chip, backup lithium battery, status LED. Common faults: touch drift, backlight damage, program loss, communication offline, low battery data loss.

Product Brief

NT296 touch panel, Omron NT series industrial HMI spare widely used for old automation cabinet overhaul and replacement.
