Omron NT631C-ST153-EV3 10.4 Inch Color HMI Programmable Terminal Unit

Feature & Principle

This color touch HMI communicates with Omron PLC through serial port. It realizes parameter setting, running status display, alarm prompt and manual operation. The front panel reaches IP65 protection grade, suitable for workshop dusty and oily environment. It supports screen project download and storage, and has backlight automatic turn-off function.

Specifications

Model: NT631C-ST153-EV3 Brand: Omron Screen: 10.4 inch TFT color LCD Resolution: 640 × 480 Color: 8 colors Power Supply: 24V DC Max Power Consumption: 18W Front Protection: IP65 Communication: Serial port for Omron PLC connection Certification: CE, UL

Components & Diagnostics

TFT display panel, resistive touch layer, main control board, backlight lamp, communication port and status indicator. Common faults: touch failure, backlight no light, screen flicker, communication interruption and program loss.

Product Brief

NT631C-ST153-EV3 HMI, Omron old series touch spare widely used for packaging machine, textile equipment and production line PLC monitoring cabinet.
