OPECLS2M18T2R-YO Through Beam Photoelectric Sensor Unit

Feature & Principle

The transmitter emits infrared light to the matched receiver. When an object blocks the light beam, the receiver changes the switching output signal. It realizes stable object presence detection, suitable for counting, product passing detection and position monitoring.

Specifications

Model: OPECLS2M18T2R-YO Brand: General optical sensor Type: Through-beam (transmitter + receiver) Housing: M18 cylindrical metal Sensing distance: 2 m Output type: NPN Power supply: 10-30VDC Connection: Cable type Protection: IP67 Certification: CE

Components & Diagnostics

Infrared emitting head, receiving head, signal circuit, indicator LED, cable. Common faults: misalignment, lens dirt, no switching output, short circuit, signal unstable.

Product Brief

OPECLS2M18T2R-YO through-beam photoelectric sensor, automation spare used for conveyor line object detection and counting.
