OPTIMATION 2-A093-0008 Fluid Fitting Assembly

Module Feature

OPTIMATION 2-A093-0008 is chemical resistant fluid pipeline fitting assembly for semiconductor wet bench. It is used for connecting process liquid pipeline, DI water and chemical delivery piping. The material features excellent resistance against dilute acid, alkali and wet bench solvent. Precision machined sealing structure prevents liquid leakage. Compact size, easy to install and replace. Widely applied in wet bench process tank, chemical delivery manifold and liquid transfer pipeline.

Working principle: This fitting connects two segments of fluid pipeline. Internal sealing structure ensures tight seal under working pressure, prevents liquid leakage. It guides process fluid flow between pipeline components and isolates external environment from corrosive process chemicals. Onboard components:Chemical resistant fitting body, built-in sealing ring, pipeline connection ports

LED indicatorsNo LED indicators, passive mechanical fluid component

Hardware self-diagnosis

Visual inspection for crack and surface corrosion, liquid pressure leak test, check sealing ring integrity.

Programming software

No configuration software required, mechanical accessory

Electrical & Process ParametersNo electrical parts, designed for liquid media transmission Working pressure:0~6 bar Working temperature:0~80℃

Mechanical & Structure

Mounting:Inline pipeline installation Material:High purity chemical resistant plastic Protection class:IP65

Environmental

Operating temperature:0℃ ~ +80℃ Ambient humidity:5~95% non-condensing Chemical resistance:Resist common wet bench process chemicals and DI water Status:OPTIMATION wet bench fluid pipeline fitting assembly

System compatibility

Compatible with OPTIMATION wet bench chemical delivery pipelines, valves, process tanks and liquid level sensor manifolds.

Function

2-A093-0008 fluid fitting assembly manufactured by OPTIMATION. It connects process liquid pipelines. Corrosion, sealing ring aging or improper installation will cause liquid leakage. It is pipeline connection spare part for semiconductor wet bench and chemical delivery automation system.

Installation

Follow lockout/tagout safety procedure before installation. Shut down chemical supply and release pipeline pressure. Install fitting into pipeline, confirm fitting direction, tighten connection, perform pressure leak test before system operation.

InterfacePipeline inlet and outlet port, built-in sealing interface.

Diagnostic

Liquid leakage:Seal ring damaged, fitting cracked or loose connection. Flow blockage:Internal contamination or particle accumulation. Fitting crack:Long term chemical corrosion or overpressure.

Product Brief

2-A093-0008 OPTIMATION chemical resistant fluid fitting assembly,for semiconductor wet bench and chemical delivery process liquid pipeline connection,corrosion resistant inline piping connector.
