PR electronics 3005 Isolated Signal Converter

Feature & Principle

It is PR electronics 3000 series ultra-slim 6mm analog signal isolation converter. It provides galvanic isolation between field transmitters and PLC input cards, eliminates ground loop interference, suppresses surge and noise. It supports standard current and voltage signal conversion, high EMC immunity, stable signal output. Configuration by DIP switch, compact structure allows dense installation on DIN rail, suitable for chemical, water treatment and marine control cabinets.

Specifications

Model: 3005 Brand: PR electronics Housing width: 6 mm Signal: 0/4-20mA, 0-10V Isolation voltage: 2.5 kVAC Power supply: 24VDC Mounting: 35mm DIN rail Temperature range: -25 ~ +70℃ Certification: CE, DNV, ATEX Zone2 optional

Components & Diagnostics

Isolation transformer, signal processing circuit, DIP switch, status LED, terminal block. Common faults: signal drift, no output, power failure, isolation breakdown.

Product Brief

3005 signal isolator, PR electronics slim analog isolation spare widely used for process control cabinet overhaul and replacement.
