PR Electronics 5202 Pulse Isolator

Feature & Principle

It is PR electronics 5202 dual-channel pulse isolation safety barrier. It receives NAMUR proximity switch or dry contact pulse signal, realizes electrical isolation between field hazardous side and safe control side. It can detect cable break and short circuit fault, output relay or open collector signal to PLC. Different suffix versions support different power supply and output types, compact DIN rail installation, widely used in chemical explosion-proof zone speed, flow, position pulse signal transmission.

Specifications

Model: 5202 Brand: PR electronics Channel: Dual channel Input: NAMUR sensor / dry contact Power supply: 24~230V AC / 24~250V DC Output: Relay / open collector NPN Mounting: 35mm DIN rail Ex certification: ATEX / IECEx Application: Chemical, petrochemical hazardous area pulse signal transmission Certification: CE, SIL optional

Components & Diagnostics

Isolation circuit, signal detection chip, relay output unit, fault indicator LED, terminal block. Common faults: cable fault alarm, no switching output, power failure, channel isolation damage.

Product Brief

5202 pulse isolator, PR electronics explosion-proof NAMUR signal spare widely used for chemical hazardous control cabinet overhaul and replacement.
