Rexroth 0360-500-00/MF01 Spare Part

Technical Specifications

Model:0360-500-00/MF01

Brand:Rexroth

Product type:Precision ball screw compact linear module

Power supply:Depends on matched servo motor

Control function:Linear position movement,high precision positioning,position feedback,hardware self-diagnosis,fault indication

Communication:Matched servo bus

Mounting:Base plate mounting

Operating temperature:0~55℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:12.8kg

Dimension:1400mm145mm120mm

Certification:CE

Protection class:IP20

System compatibility

0360-500-00/MF01 belongs to Rexroth linear motion compact module series,matched with Rexroth servo motor and drive units.Widely applied in automation assembly,press-fit and material handling workstations.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

0360-500-00/MF01 is Rexroth precision linear compact module.It adopts ball rail guide and rolled ball screw assembly to realize high-speed and high-precision linear motion.It features zero-clearance single nut structure,position repeatability up to ±0.005mm.It supports multiple lubrication options and built-in protective cover to prevent dust and debris invasion.It cooperates with servo drive to complete positioning,press-fit and automatic feeding tasks.It acts as linear motion execution component for industrial automation workstation.

Installation

Fix 0360-500-00/MF01 on the base platform and lock mounting bolts.Install matched servo motor and connect power & encoder cables following wiring drawing.Check equipment grounding before power-on.

Interface

‑Servo motor mounting flange

‑Motor encoder & power connector

‑Limit sensor terminal block

‑Status and fault LED indicator

Circuit feature

Built-in ESD and surge suppression circuit,motion signal galvanic isolation design,strong anti-interference performance for workshop industrial environment.

Feature

0360-500-00/MF01 is obsolete Rexroth spare part.Typical faults:abnormal noise during movement,position deviation,ball screw wear,guide block jamming.Inspect ball screw,guide rail and lubrication system before replacement.This linear module must match corresponding Rexroth servo system,direct replacement without inspection is not recommended.

Diagnostic

When overload,overtravel,signal loss or mechanical wear fault occurs,the system triggers protection and lights up fault LED.

Built‑in function:High precision linear positioning,reciprocating motion control,overtravel protection,status monitoring,self-diagnosis and fault alarm,used as Rexroth automation workstation spare replacement.

Product Brief

0360-500-00/MF01 is Rexroth old ball screw compact linear module for industrial automation assembly workstation.Confirm compatibility with matched servo motor and drive before ordering.ESD protection required during handling and installation.
