Rexroth 810060064 Spare Part

Technical Specifications

Model:810060064

Brand:Rexroth

Product type:Servo tightening spindle assembly

Power supply:36 Vdc

Control function:Bolt tightening rotation,torque-angle real-time output,rotary position feedback,hardware self-diagnosis,fault indication

Communication:Internal encoder bus

Mounting:Flange mounting

Operating temperature:0~55℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:1.35kg

Dimension:220mm90mm85mm

Certification:CE

Protection class:IP54

System compatibility

810060064 belongs to Rexroth servo tightening system family,matched with tightening controller,drive module and torque transducer.Widely applied in automobile assembly tightening workstations.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

810060064 serves as Rexroth servo tightening spindle.It provides rotary power to complete bolt fastening operation during assembly.It integrates built-in encoder to feed back rotation angle and speed data to controller.It cooperates with torque transducer to realize high-precision torque closed-loop control.It monitors motor winding temperature and overload status in real time and sends fault alarm to control unit.It acts as the executing power component of Rexroth tightening workstation.

Installation

Mount 810060064 through flange and lock mounting bolts.Complete power cable and encoder signal wiring according to wiring drawing.Check power polarity and equipment grounding before power-on.

Interface

‑36Vdc power input terminal

‑Encoder signal terminal block

‑Torque transducer connector

‑Status and fault LED indicator

Circuit feature

Built-in ESD and surge suppression circuit,rotary signal isolation design,strong anti-interference performance for workshop industrial environment.

Feature

810060064 is obsolete Rexroth series spare part.Typical failures include spindle no rotation,encoder signal loss,overheat alarm,output torque deviation.Check motor winding,encoder and connector pins before replacement.This spindle must match corresponding Rexroth tightening controller and drive system,direct substitution without inspection is not recommended.

Diagnostic

When overload,overheat,signal loss or internal hardware fault occurs,the module triggers protection and lights up fault LED.

Built‑in function:Rotary power output for bolt tightening,angle and speed feedback,overload protection,status monitoring,self-diagnosis and fault alarm,used as Rexroth servo tightening system spare replacement.

Product Brief

810060064 is Rexroth old servo spindle assembly for tightening assembly workstation.Confirm compatibility with corresponding controller and drive before ordering.ESD protection required during handling and installation.
