Rosemount 8800DR060SA3N1D1E2M5R10Q4Q8YP Vortex Flow Meter

Feature & Principle

It is Rosemount 8800DR series integral reducer vortex flow meter based on von Kármán vortex street principle. The integrated reducer expands the low flow measurement range while keeping standard face-to-face dimension. Adopts fully welded gasket-free non-clog structure to reduce leakage risk. Equipped with ADSP adaptive digital signal processing for strong vibration resistance. The isolated sensor can be replaced online without breaking process seal, built-in comprehensive device diagnostic functions. Suitable for measuring liquid, gas and saturated steam.

Specifications

Model: 8800DR060SA3N1D1E2M5R10Q4Q8YP Brand: Rosemount (Emerson) Series: 8800D Reducer Vortex Size: 6 inch (DN150) Output: 4-20mA, HART 7 Wetted material: 316L stainless steel Accuracy: ±0.65% for liquid, ±1% for gas and steam Turndown ratio: up to 38:1 Protection class: IP66/IP67 Certification: ATEX, IECEx, SIL2 optional Application: Petrochemical, power plant, boiler steam, process gas and liquid flow measurement

Components & Diagnostics

Vortex meter body, bluff body, isolated sensor assembly, electronic transmitter module, local LCD display, process flange and sealing components. Common faults: signal loss, abnormal vibration interference, display failure, HART communication offline, internal sensor drift.

Product Brief

8800DR060SA3N1D1E2M5R10Q4Q8YP vortex flow meter, Rosemount 8800D reducer type flow measuring spare widely used for process pipeline instrument overhaul and replacement.
