Sanyo Denki 60BA075FFW00A AC Servo Motor

Module Feature

Sanyo Denki 60BA075FFW00A belongs to SANMOTION BA series AC brushless servo motor. Rated power 750W, AC200V power class, medium inertia rotor design. Built-in high resolution rotary encoder for closed-loop position feedback. Standard 60mm square flange, compact body, high torque density, low torque ripple. High rigidity double ball bearing structure, good vibration resistance and stable low-speed performance. No built-in 24V power-off holding brake, suitable for horizontal axis applications. Widely used for medium load precision positioning axis in semiconductor wet bench and chemical delivery automation equipment.

Working principle: The matched servo amplifier outputs three-phase AC power to motor windings. The built-in encoder continuously feeds rotor angle and speed signal back to servo drive. The drive performs real-time closed-loop calculation and adjusts output current to realize precise torque, speed and position control. Without power-off brake, external mechanical locking device is required when applied to vertical load.

Onboard components:Motor stator & rotor assembly,built-in high resolution rotary encoder,heavy duty double ball bearing set,aluminum alloy housing,3-phase power connector,encoder feedback signal connector

LED indicatorsNo LED indicators on motor body; status LEDs are located on matched servo drive unit.

Hardware self-diagnosis

Visual inspection of shaft surface,connector pins and cable insulation; winding continuity and insulation resistance test; encoder signal waveform inspection; manual rotation smoothness test.

Programming software

Sanyo Denki SANMOTION servo setup software for motor parameter auto recognition, servo gain tuning and alarm log reading.

Electrical & Process Parameters

Rated power:750W Rated voltage:AC200V Rotor type:Medium inertia Feedback:Built-in high resolution rotary encoder Brake:Without holding brake Cooling:Natural air cooling

Mechanical & Structure

Mounting:60mm square flange mount Protection class:IP65 (shaft and connector area) Shaft:Keyway shaft

Environmental

Operating temperature:0℃ ~ +40℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status:Sanyo Denki SANMOTION BA series AC servo motor

System compatibility

Compatible with Sanyo Denki SANMOTION R / PQM series servo drives for automation equipment medium load axis positioning.

Function

60BA075FFW00A servo motor manufactured by Sanyo Denki. It delivers high precision rotary motion and positioning control for medium load axis. Winding damage, encoder failure or loose coupling will trigger servo alarm and stop movement. It is compact motion actuator for semiconductor wet bench and chemical delivery automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Power off servo drive system. Align motor shaft and load coupling, fasten flange mounting bolts securely. Wire motor power cable and encoder feedback cable. Configure servo parameters via SANMOTION software, perform jog test and positioning test before formal operation.

Interface3-phase power connector, encoder feedback connector on housing of 60BA075FFW00A.

Diagnostic

Motor cannot rotate:Power wiring error, servo enable signal missing. Positioning inaccuracy:Encoder fault, loose coupling or servo gain mismatch. Overheat alarm:Overloaded load, poor ventilation or bearing wear. Abnormal running noise:Bearing damage or shaft misalignment between motor and load.

Product Brief

60BA075FFW00A Sanyo Denki SANMOTION BA series 750W AC servo motor,AC200V,built-in high resolution rotary encoder,60mm flange mount,no holding brake,for semiconductor wet bench and chemical delivery medium load precision horizontal axis motion control.
