Sanyo Denki P60B18200HBF24 AC Servo Motor

Module Feature

Sanyo Denki P60B18200HBF24 is SANMOTION series high inertia AC brushless servo motor. Rated power 2.0kW, AC200V class power supply. Built-in 24V electromagnetic holding brake, suitable for vertical axis applications to lock shaft and prevent load falling during power failure. Integrated high-resolution rotary encoder for closed-loop position feedback. High rigidity bearing structure, robust against heavy load and vibration. Reinforced stator winding design, excellent continuous torque performance. Widely used for heavy load positioning axis in semiconductor wet bench and chemical delivery automation equipment.

Working principle: The matched servo amplifier outputs three-phase AC power to the motor windings. The built-in encoder continuously feeds rotor position and speed signals back to servo drive. The drive performs real-time closed-loop calculation to adjust output current and achieve precise torque, speed and position control. The 24V power-off brake locks the motor shaft when brake power is cut off to secure vertical loads.

Onboard components:Motor stator & rotor assembly, built-in high resolution rotary encoder, 24V electromagnetic holding brake, heavy duty bearing set, motor housing, power connector, encoder signal connector, brake wiring terminal

LED indicatorsNo LED indicators on motor body; status LED indicators are located on matched servo drive unit.

Hardware self-diagnosis

Visual inspection of shaft surface, connector pins and cable insulation; winding continuity and insulation resistance test; encoder signal waveform inspection; brake release and holding functional test.

Programming software

Sanyo Denki SANMOTION servo setup software for motor parameter recognition, servo gain auto tuning, alarm log reading and system diagnostics.

Electrical & Process Parameters

Rated power:2.0kW Rated voltage:AC200V Rotor type:High inertia Feedback:Built-in rotary encoder Brake:24V DC electromagnetic holding brake Cooling:Natural air cooling

Mechanical & Structure

Mounting:Flange mount Protection class:IP65 (shaft and connector area) Shaft:Keyway shaft

Environmental

Operating temperature:0℃ ~ +40℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status:Sanyo Denki high inertia AC servo motor

System compatibility

Compatible with Sanyo Denki PQM series servo drives, used for heavy load linear and rotary axis positioning of automation equipment.

Function

P60B18200HBF24 servo motor manufactured by Sanyo Denki. It delivers high torque and precise rotary positioning control for heavy loads. Winding damage, encoder failure or brake malfunction will trigger servo alarm and stop axis movement. It is heavy-duty motion actuator for semiconductor wet bench and chemical delivery automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Power off the entire servo system. Align motor shaft and load coupling, fasten flange mounting bolts securely. Wire motor power cable, encoder cable and 24V brake control wiring. Configure servo parameters, perform jog test and positioning verification before formal operation.

Interface3-phase power connector, encoder feedback connector, 24V brake control connector on housing of P60B18200HBF24.

Diagnostic

Motor cannot rotate:Power wiring error, servo enable missing or brake not released. Positioning inaccuracy:Encoder fault, loose coupling or servo gain mismatch. Overheat alarm:Overloaded load, poor ventilation or bearing damage. Abnormal noise:Bearing wear or shaft misalignment between motor and load.

Product Brief

P60B18200HBF24 Sanyo Denki SANMOTION 2.0kW high inertia AC servo motor,AC200V,with built-in 24V holding brake,flange mount,for semiconductor wet bench and chemical delivery heavy load vertical axis motion positioning.
