Sanyo Denki 67ZA030A821S00 Servo Amplifier

Module Feature

Sanyo Denki 67ZA030A821S00 belongs to SANMOTION 67ZA series compact digital AC servo amplifier. Rated capacity 300W, adopts current and speed dual closed-loop control architecture, fast response characteristic and low speed fluctuation. Compatible with Sanyo Denki Q series and P10 series small frame servo motors. Supports pulse train and analog signal two command input modes. Built-in comprehensive protection functions including overcurrent, overvoltage, undervoltage, overheat, overload, encoder abnormality and emergency stop protection. DIN rail mounting, compact housing, small footprint for electrical cabinet installation. Widely used for small load precision positioning axis in semiconductor wet bench and chemical delivery automation equipment.

Working principle: The servo drive receives motion command signal from upper controller. It converts input AC power into three-phase variable frequency AC power to drive matched servo motor. Real-time collects encoder feedback signal from motor, executes high speed closed-loop calculation to adjust output current, realizes precise control of torque, speed and position. Once fault condition is detected, the amplifier will immediately cut off power output and send alarm signal to host system.

Onboard components:Power IGBT module,main digital control PCB,pulse/analog command terminal block,encoder feedback port,DC bus terminal,front panel LED status indicators,emergency stop terminal

LED indicatorsFront panel LED indicators for power, servo ready, enable state, fault alarm and communication status.

Hardware self-diagnosis

Visual inspection of power terminals and encoder connector; power-on self-test; input voltage detection; motor wiring continuity test; alarm code reading and signal loopback verification.

Programming software

Sanyo Denki SANMOTION setup software for motor parameter auto recognition, servo gain tuning, command mode configuration and fault log reading.

Electrical & Process Parameters

Input voltage:AC200V class Rated capacity:300W Control mode:Position / Speed / Torque Command input:Pulse train, analog signal Protection:Overcurrent, overvoltage, undervoltage, overheat, overload, encoder fault, E-stop Mounting:DIN rail

Mechanical & Structure

Mounting:Cabinet DIN rail installation Protection class:IP20

Environmental

Operating temperature:0℃ ~ +50℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status:Sanyo Denki SANMOTION 67ZA compact AC servo amplifier

System compatibility

Compatible with Sanyo Denki Q series and P10 series small frame servo motors for automation small load axis positioning.

Function

67ZA030A821S00 servo drive manufactured by Sanyo Denki. It provides power driving and closed-loop control for matched servo motor, realizes stable low-speed operation and high precision positioning. Improper encoder wiring, mechanical overload or parameter mismatch will trigger servo alarm and stop movement. It is compact motion control driver for semiconductor wet bench and chemical delivery automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Power off the whole servo system. Mount servo drive on DIN rail and reserve heat dissipation clearance. Wire AC power cable, motor power cable and encoder feedback cable. Connect control signal and emergency stop circuit. Configure parameters via SANMOTION software, complete jog test and positioning verification before formal operation.

InterfaceAC power input terminal, motor power output terminal, encoder feedback connector, pulse/analog control signal terminal block, emergency stop terminal, front LED status indicators on housing of 67ZA030A821S00.

Diagnostic

Servo not ready:Power supply missing or internal hardware damage. Motor no movement:Servo enable signal missing, wiring error or wrong motor parameter. Overload alarm:Mechanical jamming, excessive load or motor winding defect. Encoder alarm:Encoder cable broken, poor contact or encoder failure.

Product Brief

67ZA030A821S00 Sanyo Denki SANMOTION 67ZA compact AC servo drive,300W rated capacity,dual loop digital control,supports pulse/analog command,DIN rail mount,matching Q/P10 series servo motors,for semiconductor wet bench and chemical delivery small load precision motion axis control.
