Sanyo Denki BP060RXB1 #GY-3 Servo Motor

Module Feature

Sanyo Denki BP060RXB1 #GY-3 belongs to BL Super series high performance AC servo motor. Rated power 0.6kW, 3-phase AC200V power supply, 50/60Hz. It adopts high torque density permanent magnet rotor design, matched with digital servo drive for position, speed and torque closed-loop control. Built-in high resolution incremental encoder for real-time rotor position feedback. Multiple internal thermal and current monitoring protection functions. Compact mechanical structure, good vibration resistance. Widely applied in precision positioning axis for semiconductor equipment and industrial automation machinery.

Working principle

The servo amplifier outputs variable frequency three-phase AC power to drive the motor stator winding. The permanent magnet rotor rotates under the action of rotating magnetic field. The built-in incremental encoder continuously feeds back rotor position and speed data to the servo drive. The drive executes high-speed closed-loop calculation to adjust output current, so as to realize precise torque, speed and position control. When abnormal temperature or overcurrent occurs, the motor triggers protection and stops operation to avoid component damage.

Onboard components

Permanent magnet rotor, stator winding, incremental encoder assembly, thermal sensor, power terminal block, encoder signal connector, front/rear bearing set, motor housing and shaft seal.

LED indicators

No onboard LED indicators; status and alarm information are displayed on matched servo amplifier panel.

Hardware self-diagnosis

Visual inspection of motor housing, shaft, connectors and cable surface; winding insulation resistance test; encoder signal continuity check; bearing noise inspection; power-on feedback signal verification with matched servo drive.

Programming software

Sanyo Denki SANMOTION setup software for motor parameter matching, gain tuning and fault alarm log reading.

Electrical & Process Parameters

Model: BP060RXB1 #GY-3 Input voltage: 3-phase AC200V,50/60Hz Rated power: 0.6kW Control mode: Position / Speed / Torque (depends on matched drive) Encoder type: Incremental encoder Cooling: Natural cooling Protection: Overcurrent, overload, overtemperature, encoder fault Mounting: Flange mounting

Mechanical & Structure

Mounting: Flange mounting Protection class: IP65

Environmental

Operating temperature: 0℃ ~ +40℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: Sanyo Denki BL Super series AC servo motor

System compatibility

Compatible with Sanyo Denki BL Super series servo amplifiers to form complete motion control system for precision axis positioning.

Function

BP060RXB1 #GY-3 servo motor manufactured by Sanyo Denki. It converts electrical energy into mechanical rotation power under the control of servo amplifier, to realize high precision positioning, speed regulation and torque output for automation motion axis. Overload, wiring fault or encoder damage will trigger system alarm and stop motor operation. It is precision power execution unit for semiconductor and industrial automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Power off the whole servo system completely. Fix motor via flange mounting, align mechanical coupling properly to avoid radial and axial overload. Wire motor power cable and encoder feedback cable to servo drive. Set motor parameters via SANMOTION software, perform jog test and positioning verification before formal operation.

Interface

Motor power terminal, incremental encoder signal connector, motor housing of BP060RXB1 #GY-3.

Diagnostic

Motor no rotation: Servo enable signal missing, wrong wiring or mismatched motor parameters. Overload alarm: Excessive mechanical load, coupling jam or mechanical stuck. Encoder alarm: Damaged encoder cable, poor connector contact or encoder failure. Overtemperature alarm: Continuous heavy load operation, poor heat dissipation or bearing failure. Insulation fault: Damaged stator winding or cable insulation aging.

Product Brief

BP060RXB1 #GY-3 Sanyo Denki BL Super series AC servo motor,3-phase AC200V, rated power 0.6kW, built-in incremental encoder, IP65 protection, flange mount, matched with BL Super servo amplifiers,for semiconductor automation and industrial precision motion axis control.
