Sanyo Denki P20BA300FFW83 BL900M Brushless DC Motor

Module Feature

Sanyo Denki P20BA300FFW83 BL900M is BL series high-performance DC brushless motor assembly. It adopts permanent magnet brushless structure, eliminating carbon brush wear for extended service life. Built-in hall position sensor for real-time speed and rotor position feedback. Features high torque density, low heat generation and low running noise. Robust housing design with excellent shock and vibration resistance. Widely used in semiconductor automation equipment, precision conveying systems and industrial automation positioning axes.

Working principle

The matched BL series brushless driver provides DC power to the stator winding. The built-in hall sensor continuously detects rotor position and transmits position signals back to the driver. The driver performs electronic commutation to drive the permanent magnet rotor to rotate. Closed-loop control maintains stable torque and speed output. Internal protection circuit will shut down output when overcurrent, locked rotor or overtemperature fault is detected to protect the motor assembly.

Onboard components

Permanent magnet rotor, stator winding, hall position sensor assembly, front and rear bearing set, motor housing, shaft oil seal, power and signal terminal connector.

LED indicators

No onboard LED indicators; working state and fault codes are displayed on the matched brushless driver panel.

Hardware self-diagnosis

Visual inspection of motor housing, shaft surface and connectors; winding continuity and insulation resistance test; hall sensor signal detection; bearing abnormal noise inspection; feedback signal verification with matched driver.

Programming software

Sanyo Denki SANMOTION setup software for parameter configuration, speed gain tuning and fault log reading.

Electrical & Process Parameters

Model: P20BA300FFW83 BL900M Input voltage: DC24V Control mode: Speed / Torque Signal: Hall position feedback Cooling: Natural cooling Protection: Overcurrent, overload, overtemperature, locked rotor protection Mounting: Flange mounting

Mechanical & Structure

Mounting: Flange mounting Protection class: IP64

Environmental

Operating temperature: 0℃ ~ +40℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: Sanyo Denki BL series DC brushless motor

System compatibility

Compatible with Sanyo Denki BL series brushless drivers to form complete DC brushless motion control system for precision transmission and positioning.

Function

P20BA300FFW83 BL900M brushless motor manufactured by Sanyo Denki. It converts DC electric energy into mechanical rotary power under the control of matched brushless driver, delivering stable speed regulation and constant torque output for automation motion axes. Overload, wiring error or sensor damage will trigger system alarm and stop motor operation. It is reliable power execution unit for semiconductor and industrial automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all power supply completely. Fix motor via flange mounting, align coupling properly to avoid radial and axial overload. Connect power cable and hall feedback cable to brushless driver. Set parameters via SANMOTION software, perform trial rotation and performance verification before formal operation.

Interface

Motor power terminal, hall sensor signal connector, motor housing of P20BA300FFW83 BL900M.

Diagnostic

Motor no rotation: No DC power supply, reversed wiring or hall sensor failure. Overload alarm: Excessive mechanical load, coupling jam or mechanical stuck. No speed feedback: Damaged signal cable or hall sensor damage. Overtemperature alarm: Continuous heavy load operation, poor heat dissipation or bearing failure. Insulation fault: Damaged stator winding or cable insulation aging.

Product Brief

P20BA300FFW83 BL900M Sanyo Denki BL series DC brushless motor,DC24V power supply,built-in hall position sensor,high efficiency low noise design,IP64 protection,flange mount,matched with BL series brushless drivers,for semiconductor automation and industrial precision transmission control.
