Sanyo Denki PQM0A300EXXXST Servo Amplifier

Module Feature

Sanyo Denki PQM0A300EXXXST belongs to SANMOTION PQM series modular multi-axis digital servo amplifier. AC200V input, rated capacity 3.0kW. It adopts high speed RS485 serial bus control interface, supports multi-axis synchronous motion control, electronic cam and interpolation function. Equipped with current and speed dual closed-loop control, fast response and excellent anti-vibration performance. Supports position, speed, torque three control modes. Built-in comprehensive protection functions including overcurrent, overvoltage, undervoltage, overheat, overload, encoder fault and emergency stop protection. Modular rack mounting design, multiple axes share the same power supply unit, saving cabinet installation space. Widely used for multi-axis high precision motion system in semiconductor wet bench and chemical delivery automation equipment.

Working principle: The servo amplifier receives motion command via high speed serial bus from upper motion controller. It converts DC bus power into three-phase variable frequency AC power to drive matched P series servo motors. Real-time encoder position and speed feedback signal is sent back to drive, high speed digital closed-loop calculation is executed to adjust output current to realize precise multi-axis synchronous positioning. When fault detected, the amplifier will cut off power output immediately and send alarm information to host controller.

Onboard components:Power IGBT module,digital main control PCB,serial communication port,encoder feedback connector,DC bus terminal,front panel LED status indicators,emergency stop terminal

LED indicatorsFront panel LED indicators for power, servo ready, enable status, fault alarm and communication link.

Hardware self-diagnosis

Visual inspection of DC bus terminals and encoder connectors; power-on self-test; bus voltage detection; motor wiring continuity inspection; read alarm history and verify serial communication loop.

Programming software

Sanyo Denki SANMOTION setup software for motor parameter auto recognition, servo gain tuning, electronic cam configuration and alarm log reading.

Electrical & Process Parameters

Input voltage:AC200V class Rated capacity:3.0kW Control mode:Position / Speed / Torque Command interface:High speed RS485 serial bus Protection:Overcurrent, overvoltage, undervoltage, overheat, overload, encoder fault, E-stop Mounting:Modular rack mount

Mechanical & Structure

Mounting:Rack modular installation Protection class:IP20

Environmental

Operating temperature:0℃ ~ +50℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status:Sanyo Denki SANMOTION PQM multi-axis digital servo amplifier

System compatibility

Matched with Sanyo Denki P series high power servo motors, used for automation multi-axis synchronous heavy load positioning.

Function

PQM0A300EXXXST servo amplifier manufactured by Sanyo Denki. It provides modular power drive and high speed bus closed-loop control for matched servo motors, realizes multi-axis synchronization and complex cam motion. Improper bus wiring, mechanical overload or wrong parameter setting will trigger servo alarm and stop movement. It is high performance multi-axis motion control unit for semiconductor wet bench and chemical delivery automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Power off the whole servo rack system. Install servo amplifier into rack frame and reserve heat dissipation clearance. Wire DC bus cable, motor power cable and encoder feedback cable. Connect serial communication cable and emergency stop circuit. Configure parameters via SANMOTION software, perform axis jog test and multi-axis synchronization verification before formal operation.

InterfaceDC bus input terminal, motor power output terminal, encoder feedback connector, RS485 serial communication port, emergency stop terminal, front LED indicators on housing of PQM0A300EXXXST.

Diagnostic

Servo not ready:Power supply missing or internal hardware damage. Communication alarm:Serial cable broken, poor contact or address conflict. Overload alarm:Mechanical jam, overload or motor winding defect. Encoder alarm:Cable damage, poor contact or encoder failure.

Product Brief

PQM0A300EXXXST Sanyo Denki SANMOTION PQM 3.0kW multi-axis servo amplifier,AC200V class,high speed RS485 serial bus interface,modular rack mount,matching P series servo motors,for semiconductor wet bench and chemical delivery multi-axis synchronous heavy load precision motion control.
