Schneider LC1F4002 Contactor

Feature & Principle

It is a coil-less main contactor body of Schneider TeSys F series. After matching a separate LX1/LX9/LXE excitation coil, the electromagnetic coil generates magnetic force to pull the movable contact, switch on or cut off the main circuit. It is designed for AC-1 resistive load working condition, suitable for long-time on-load switching of heating pipes, capacitor groups and other non-inductive loads, with strong overload resistance and high breaking capacity.

Specifications

Model: LC1F4002 Brand: Schneider Series: TeSys F Pole: 2P, 2NO Utilization category: AC-1 Rated operational current: 500A Max operational voltage: 1000V Control coil: Sold separately (LX1 / LX9 / LXE series) Rated impulse withstand voltage: 8kV Lifecycle: Discontinued legacy spare Application: Heating cabinet, capacitor compensation cabinet, resistive load control Certification: CE, UL

Components & Diagnostics

Main contact assembly, electromagnetic yoke, arc extinguishing chamber, mounting bracket, terminal studs. Common faults: contact ablation, poor contact, arc extinguishing cover damage, mechanical jamming.

Product Brief

LC1F4002 high power contactor body, Schneider TeSys F series electrical spare widely used for heating and capacitor cabinet overhaul and replacement.
