Siemens 6ES7417-4HT14-0AB0 CPU Module

Feature & Principle

It is the CPU417H redundant controller of Siemens S7-400H series fault-tolerant PLC. Two CPU units work in primary-standby mode and synchronize data via fiber sync link. When the master CPU fails, bumpless hot switchover is triggered to ensure continuous operation of the control system. It supports large program memory, high-speed processing, PROFIBUS-DP and industrial Ethernet communication. Program configuration and diagnosis are implemented via STEP7 software, suitable for occasions requiring high system availability.

Specifications

Model: 6ES7417-4HT14-0AB0 Brand: Siemens Series: SIMATIC S7-400H Type: Redundant CPU417H Work memory: 30MB program + 30MB data Communication: MPI, PROFIBUS DP, Industrial Ethernet Sync: Fiber optic synchronization module Power supply: 5V backplane Mounting: S7-400 rack slot installation Application: Petrochemical, power plant, chemical continuous process control Certification: CE, UL

Components & Diagnostics

CPU mainboard, sync fiber interface, backplane bus interface, status LED, watchdog circuit. Common faults: synchronization link abnormal, CPU sync mismatch, communication interruption, power failure, program loss.

Product Brief

6ES7417-4HT14-0AB0 redundant CPU, Siemens S7-400H fault tolerant control spare widely used for high availability DCS and PLC cabinet overhaul and replacement.
