ProSoft MVI56 Communication Module

Feature & Principle

It is a single-slot communication gateway series developed by ProSoft for Allen-Bradley ControlLogix 1756 rack. Different suffix versions support Modbus, PROFIBUS, HART, ASCII and other industrial protocols. It exchanges data with ControlLogix CPU through backplane bus, and realizes protocol conversion between PLC and field instruments, drives and other third-party equipment. It has built-in register buffer for data mapping, configured by ProSoft Configuration Builder software. This classic series has been discontinued and widely used as maintenance spare for old automation control systems.

Specifications

Model: MVI56 series Brand: ProSoft Technology Applicable rack: Allen-Bradley 1756 ControlLogix Installation: Single slot chassis mount Backplane: ControlLogix backplane Operating temperature: 0 ~ 60℃ Internal register: Up to 5000 words Status display: Scrolling LED diagnostic display Application: Petrochemical, water treatment, power plant, production line multi-protocol networking Certification: CE, UL

Components & Diagnostics

Main control PCB, backplane interface circuit, communication transceiver chip, flash memory, status LED indicator. Common faults: module cannot handshake with CPU, communication port no signal, register data disorder, firmware loss, power supply damage.

Product Brief

MVI56 communication module, ProSoft ControlLogix multi-protocol gateway spare widely used for PLC cabinet overhaul and replacement.
