SVAHX-S Powder Butterfly Valve

Feature & Principle

The pneumatic actuator receives air signal to drive the valve plate to rotate, so as to open or close the flow channel of powder medium. The special flexible seal can compensate the gap between valve plate and valve body to prevent powder leakage. Fail-safe design is optional, the valve will return to preset position when air supply is lost. It can be equipped with limit switch to feed back valve position signal to PLC.

Specifications

Model: SVAHX-S Type: Pneumatic powder butterfly valve Body material: Aluminum alloy Disc material: Stainless steel AISI304 Seal: NBR / HNBR Working pressure: -0.2~0.2 bar Medium: Powder, dust, granular material Working temperature: -20℃ ~ +100℃ Connection: Double flange Certification: CE

Components & Diagnostics

Pneumatic actuator, valve body, stainless steel disc, sealing ring, limit switch, air port connector. Common faults: powder leakage from sealing surface, valve plate stuck, actuator not responding, limit signal loss, seal wear.

Product Brief

SVAHX-S powder butterfly valve, bulk material control spare widely used for dust removal system, cement plant and grain conveying pipeline maintenance and replacement.
