T1022300-AN Vibration Transmitter Unit

Feature & Principle

It adopts piezoelectric effect principle. Internal piezo element converts mechanical vibration acceleration into charge signal, the built-in circuit conditions and converts it into standard 4-20mA current signal. The signal is sent to PLC or monitoring system for vibration trending, alarm and interlock protection of rotating equipment.

Specifications

Model: T1022300-AN Sensing principle: Piezoelectric Output: 4-20mA Power supply: 10~30VDC Measurement: Velocity vibration Housing: Stainless steel Mounting: Thread stud installation Protection grade: IP67 Certification: CE

Components & Diagnostics

Piezoelectric chip, signal conditioning circuit, stainless steel housing, cable connector. Common faults: signal loss, amplitude drift, resonance interference, connector loose, internal cable breakage.

Product Brief

T1022300-AN vibration transmitter, machinery condition spare widely used for pump, fan, compressor and gearbox online vibration monitoring.
