T10F Molded Case Circuit Breaker

Feature & Principle

It is fixed frame molded case circuit breaker. It adopts current limiting arc extinguishing structure. Thermal magnetic trip version realizes overload long delay and short circuit instantaneous protection; electronic trip version supports adjustable LSI/LSIG protection. It can be equipped with auxiliary contact, alarm contact, shunt release and undervoltage release. F stands for standard breaking capacity, compact structure, easy panel mounting, widely used for factory workshop, commercial building distribution cabinet branch loop protection.

Specifications

Model: T10F Type: Fixed MCCB Pole: 3P / 4P Rated voltage: Up to 690V AC Trip option: Thermal magnetic / electronic trip Breaking grade: F Standard: IEC 60947-2 Installation: Fixed mounting Application: Industrial distribution cabinet, building power distribution, branch feeder protection Certification: CE

Components & Diagnostics

Insulated housing, contact assembly, arc extinguishing chamber, trip unit, operating mechanism, auxiliary switch optional. Common faults: contact overheating, mis-trip, mechanism stuck, trip unit failure.

Product Brief

T10F molded case circuit breaker, low voltage distribution spare widely used for power distribution cabinet maintenance and replacement.
