XTJP-G11-L1 Proximity Sensor Unit

Feature & Principle

It adopts electromagnetic induction principle. The internal oscillator generates alternating magnetic field. When metal target enters the sensing range, eddy current is generated to attenuate oscillation. The circuit judges the signal and outputs switching signal, no mechanical contact, long service life, suitable for high-frequency detection and limit interlock.

Specifications

Model: XTJP-G11-L1 Type: Inductive proximity switch Power supply: 10~30VDC Output type: NPN / PNP Sensing distance: Standard detection range Connection: Cable type Protection: IP67 Certification: CE

Components & Diagnostics

Oscillation coil, signal processing circuit, metal housing, cable and sealing assembly. Common faults: no detection signal, false triggering, cable breakage, water ingress, output failure.

Product Brief

XTJP-G11-L1 proximity switch, sensor spare widely used for conveyor, packaging machinery, machine tool and automated production line position detection.
