11305473 Wiring Harness Assembly Unit

Module Feature

11305473 is a factory pre-assembled wiring harness spare part for industrial automation cabinet.

It adopts multi-core shielded twisted pair cable structure, both ends pre-crimped and terminated with specified connectors or terminal lugs, fixed wiring length and pin definition according to drawing specification. The overall shielding design suppresses EMC interference for low-level analog signals and digital bus signals. It is used for internal interconnection between controller, I/O module, terminal board and field junction box. This harness is supplied as a direct replacement spare for legacy control system cabinet maintenance.

Working principle

The harness provides stable signal transmission path between different control components.

Shield layer properly grounded to reduce electromagnetic noise induced by variable frequency drives and high-power equipment. Each wire follows defined pin assignment to transmit DC power, analog 4-20mA signal, DI/DO discrete signal or serial bus signal.

Onboard components

Multi-core shielded cable, tin-plated copper conductors, insulation jacket, braided shielding mesh, heat shrink tubing, crimp terminals, circular / rectangular connectors, cable tie fixing components.

LED indicators

Not applicable, passive wiring assembly without electronic indicator. Signal health needs to be verified by host module diagnostic function.

Hardware self‑diagnosis

No built-in self-diagnosis. Field inspection includes continuity test, insulation resistance test, shield continuity and connector pin short/open check.

Programming software

Not applicable.

Electrical & Process Parameters

Model:11305473 Brand:Custom OEM wiring assembly Device type:Pre-terminated shielded signal cable harness Function:Signal and auxiliary power interconnection inside industrial control cabinet

Mechanical & Structure

Mounting:Cabinet internal routing, fixed by cable clips Protection class:IP20 inside cabinet Housing:PVC / PUR insulated outer jacket, braided shield

Environmental

Operating temperature:-20℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing

Certification:CE, IEC

Status:Original OEM control cabinet wiring spare

Installation

Route harness inside cabinet away from high voltage power cables.

Check pinout definition before mating connectors, secure cable routing and connect shield grounding point as drawing requirement.

Interface

Custom defined male/female connector sets or bare terminal lugs.

Diagnostic

Signal intermittent: Connector pin loose, shield broken or cable internal conductor fracture. Short circuit fault: Insulation damaged, pin to pin short inside connector. High signal noise: Shield grounding missing or single-point grounding violated.

Product Brief

11305473 wiring harness assembly, pre-terminated shielded signal cable spare for DCS and turbine control cabinet replacement.
