460-413-017 Eddy Current Probe Inquiry Item

Feature & Principle

The internal sensing coil generates high-frequency alternating magnetic field. Eddy current will be induced on the surface of the metal rotating shaft when it enters the magnetic field. The impedance variation of the coil is converted into linear voltage signal, which reflects the gap distance between probe and shaft. Non-contact design eliminates mechanical wear, built-in shielding structure suppresses electromagnetic interference on site.

Specifications

Model: 460-413-017 Type: Eddy current proximity probe Measurement object: Conductive metal shaft Working temperature: -40℃ ~ +125℃ Matching accessory: 460 series extension cable Mounting form: Thread mounting Application: Steam turbine, gas turbine, centrifugal compressor Certification: CE

Components & Diagnostics

Stainless steel probe housing, internal sensing coil, insulating filling material, integrated connector. Common faults: coil burnout, zero drift, signal loss, poor connector contact, probe surface scratch.

Product Brief

460-413-017 eddy current probe, rotating machinery monitoring spare widely used for power plant turbine and large rotating equipment protection system overhaul and replacement.
