8X8 CCTV Video Matrix Surveillance System Unit

Module Feature

8X8 CCTV system is a video matrix switching system with 8 camera signal inputs and 8 monitor outputs.

It routes any incoming camera video signal to any selected display channel, supporting manual switching, auto-sequencing and group switching modes. It works with analog CCTV cameras, coaxial cable transmission and CRT/LCD monitors. It can be expanded with alarm trigger function and keyboard controller, commonly deployed for perimeter security, production area monitoring and critical site visual inspection.

Working principle

Composite video signals from 8 cameras are fed into the matrix input ports.

Internal analog switching circuit connects selected input channel to assigned output port. Operators use control keyboard to switch viewing channels, or set automatic dwell sequence to cycle camera feeds on monitors. Alarm signal can trigger automatic pop-up of associated camera video.

Onboard components8-channel video matrix host, CCTV analog cameras, coaxial BNC cables, power adapters, monitor displays, control keyboard, alarm terminal block.

LED indicators

Front LEDs indicate power ready, selected input channel status, alarm trigger and video signal presence.

Hardware self‑diagnosis

Built-in supervision detects video signal loss and communication failure with control keyboard. Signal loss warning will show when camera cable is open or camera power fails.

Programming software

Matrix configuration utility, used for sequence dwell time setting, alarm linkage setup and channel naming.

Electrical & Process Parameters

Model:8X8 CCTV SYSTEM Brand:General surveillance specification Device type:Analog video matrix security monitoring system Function:Video signal switching and distribution for multi-camera security surveillance

Mechanical & Structure

Mounting:Standard 19-inch rack installation Protection class:IP20 for matrix host Housing:Metal rack-mount chassis enclosure

Environmental

Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing

Certification:CE, FCC

Status:General industrial security surveillance system

Installation

Route BNC coaxial cables from each camera to matrix input terminals.

Connect output ports to monitors, set sequence and alarm linkage parameters before power-on test.

Interface

BNC video input ports, BNC video output ports, RS485 keyboard control port, alarm signal terminal block.

Diagnostic

No video image: Camera power failure, BNC connector loose or coaxial cable breakage.

Rolling or distorted picture: Ground loop interference, improper cable shielding or signal attenuation.

Keyboard control invalid: RS485 wiring reversed, wrong address setting or communication line broken.

Product Brief

8X8 CCTV system, 8-in 8-out analog video matrix surveillance system for factory, substation and industrial site security monitoring.
