ABB 3BHE032593R0001 Power Supply Module

Feature & Principle

It is ABB IPS21 isolated DC power supply module, widely used for Unitrol generator excitation control system. It provides galvanic isolation between input and output to suppress ground loop interference and noise. It converts input voltage to stable 24VDC output for controller boards, signal circuits and auxiliary I/O. Built-in overvoltage, overcurrent and short-circuit protection circuits. This model is discontinued and commonly used as replacement spare in power plant excitation cabinets.

Specifications

Model: 3BHE032593R0001 Brand: ABB Alternative code: IPS21-24V-35AD Output: 24 V DC, 35 A Power rating: 840 W Isolation: Galvanic isolation Protection: Overvoltage, overcurrent, short circuit Mounting: Cabinet chassis mounting Operating temperature: -20 ~ +70℃ Application: Generator excitation cabinet, power plant control system, industrial DCS cabinet Certification: CE

Components & Diagnostics

Power conversion circuit, isolation transformer, rectifier assembly, electrolytic capacitors, status LED indicators, terminal block. Common faults: capacitor swelling, no output, unstable voltage, overheat alarm, internal short circuit.

Product Brief

3BHE032593R0001 power supply module, ABB IPS21 isolated power spare widely used for generator excitation cabinet overhaul and replacement.
