ABB 3BSE000860R1 SB510 Backup Power Supply Module

Technical Specifications

Model:3BSE000860R1(SB510)

Brand:ABB

Product Type:Backup power supply battery module

Power Supply:24VDC system bus power

Battery Type:Built‑in rechargeable nickel‑cadmium battery

Function:Memory data backup when main power supply lost,prevent parameter and program loss

Protection:Over‑charge,over‑discharge,short‑circuit protection

Indicator:Front‑panel LED for battery status and fault alarm

Feature:DIN rail mounting,compact modular structure,battery service life monitoring

System Compatibility:ABB Advant OCS,S100 I/O control system

Remark:Legacy EOL spare component;check battery aging status before commissioning

Module Form:DIN rail plug‑in module

Weight:0.65 kg

Dimension:125 mm×85 mm×40 mm

Protection Grade:IP20

Certification:CE

Working Temperature:‑10℃ ~ +60℃,non‑condensing

Storage Temperature:‑40℃ ~ +85℃

Humidity:5%‑95% non‑condensing

Application:Petrochemical,power plant,paper‑making industry,provide power backup for controller memory,protect program and configuration data during power outage,system overhaul and spare‑part replacement.

Product Details

3BSE000860R1,type SB510,is dedicated backup power battery module for ABB Advant OCS and S100 I/O DCS system. It supplies short‑term backup power for controller memory when main power fails,to avoid loss of user programs,parameters and configuration data.

Equipped with built‑in rechargeable nickel‑cadmium battery,complete charge‑discharge protection circuit. LED indicators show battery health and fault status. DIN‑rail installation,easy for replacement. Battery aging will cause backup failure,resulting in program loss after power‑off. Widely used for maintenance of old‑generation Advant OCS control system.

Note:This is legacy EOL spare component,widely used for DCS system spare‑part replacement.
