ABB 3BSE042235R2 PP845A Touch Screen Operator Panel

Technical Specifications

Model:3BSE042235R2(PP845A)

Brand:ABB

Product Type:Panel800 series touch screen operator panel

Display:10.4‑inch TFT‑LCD,800×600 resolution,CCFL backlight

Touch Type:Analog resistive touch screen

Power Supply:24VDC(18‑30VDC)

Communication Interface:Ethernet,RS232 serial port

Function:Process data display,parameter setting,on‑site operation,fault alarm display,real‑time monitoring

Feature:Front‑panel IP65 protection,panel mounting,Panel Builder configuration tool support

System Compatibility:ABB System 800xA DCS control system

Remark:Legacy EOL spare component;confirm project firmware version before replacement

Module Form:Panel‑mount integrated HMI unit

Weight:2.04 kg

Dimension:302 mm×230 mm×60 mm

Protection Grade:Front IP65,Rear IP20

Certification:CE

Working Temperature:0℃ ~ +50℃,non‑condensing

Storage Temperature:‑40℃ ~ +85℃

Humidity:5%‑85% non‑condensing

Application:Petrochemical,power plant,papermaking,metallurgy industry,as local operation monitoring unit for System800xA DCS system,complete field process monitoring,parameter modification,fault viewing,equipment overhaul and spare‑part replacement.

Product Details

3BSE042235R2,type PP845A,is ABB Panel800 series 10.4‑inch touch‑screen operator panel,specially matched with System 800xA DCS platform.

Adopts 800×600 TFT‑LCD display with resistive touch,front‑panel reaches IP65 to adapt to workshop on‑site environment. It connects to DCS controller via Ethernet,realizes process picture display,loop parameter adjustment,alarm information check and on‑site manual operation. Configured by Panel Builder software. HMI failure will cause local operation failure,unable to view field real‑time data. Widely used for transformation and spare‑part replacement of old‑generation 800xA project.

Note:This is legacy EOL spare component,widely used for process industry spare‑part replacement.
