ABB 3BSE083204R1 TUS810K01 Select I/O Termination Unit Kit

Module Feature

3BSE083204R1 is the complete kit part number for ABB TUS810K01 modular termination unit (MTU) under Select I/O series for System 800xA DCS.

The assembly acts as mechanical carrier and field signal interface for single-channel SCM signal conditioning modules. It supports self-coding locking mechanism: each FTB terminal block remembers the installed SCM type to prevent wrong module replacement. It accepts analog, digital, HART and intrinsically safe SCM modules, suitable for SIL3 safety instrumented loops. Vertical DIN rail mounting saves cabinet space, each MTU supports maximum 16 signal channels. The package is pre-configured set including base, field terminals, power feed terminals and protective cover. Widely stocked as maintenance spare for power plant, chemical and oil & gas 800xA control cabinet.

Working principle

Field sensor and actuator wiring terminates on FTB810 field terminal blocks.

Terminal block routes signals to the inserted SCM conditioning module, while PTB810 provides loop power injection for 4-20mA instruments. The TUS810 backplane communicates with GIO gateway module via internal bus, converting field signals into Ethernet Select I/O protocol for 800xA controller. Built-in channel disconnect function allows loop isolation without removing wiring. Coding pins restrict mismatched SCM swap to avoid configuration error.

Onboard components

TUS810 MTU base backplane, 16pcs FTB810 field terminal blocks, 2pcs PTB810 power injection terminal blocks, TUC810 plastic protective cover, coding mechanism, internal signal bus and DIN rail mounting clip.

LED indicators

Status indicators are located on matched SCM and GIO gateway module, no LED on TUS810 base.

Hardware self‑diagnosis

Channel diagnostics, SCM presence and coding check are processed by SCM module and 800xA engineering environment. Configuration and diagnostic view are completed by ABB Control Builder M software.

Programming softwareControl Builder M, used for channel assignment, SCM parameter setup, HART configuration and fault alarm monitoring.

Electrical & Process Parameters

Model:3BSE083204R1 Brand:ABB Device type:TUS810K01 Select I/O modular termination unit kit Function:Field signal termination, power feed and mechanical support for Select I/O SCM modules

Mechanical & Structure

Mounting:Vertical DIN rail installation inside control cabinet Protection class:IP20 Housing:Plastic base + removable terminal cover

Environmental

Operating temperature:-20℃ ~ +60℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing

Certification:CE, IEC61508 SIL3 capable, ATEX optional Status:Original ABB 800xA DCS I/O spare

Installation

Cut off field loop power before replacement.

Mount base on DIN rail, wire field cable to FTB terminals, insert SCM modules, confirm coding lock status, download I/O configuration and test channel communication after commissioning.

Interface

Field wiring terminals, SCM module slot interface, internal backplane bus to GIO gateway, loop power injection terminals.

Diagnostic

Module mismatch alarm: SCM coding conflict, wrong module type inserted. No channel communication: Terminal block loose, backplane contact poor. Loop power loss: PTB810 power terminal fault.

Product Brief3BSE083204R1 kit, ABB TUS810K01 Select I/O termination unit spare for System 800xA DCS cabinet replacement.
