ABB 57310001‑KN DSDI110 Digital Input Module

Technical Specifications

Model:57310001‑KN(DSDI110)

Brand:ABB

Product Type:S100 series digital input module

Signal Type:24VDC digital input

Channel Quantity:16 channels DI

Input Signal Range:18‑30VDC

Isolation:Channel‑to‑bus galvanic isolation

Interface:Front screw terminal block,backplane rack bus connector

Indicator:Per‑channel LED status indicator

Feature:Rack plug‑in installation,on‑board signal filtering

System Compatibility:ABB Advant Master,MasterPiece,S100 I/O DCS system

Remark:Legacy EOL spare component;confirm rack backplane matching requirement before replacement

Module Form:Rack‑mount plug‑in PCB board

Weight:0.35 kg

Dimension:230 mm×100 mm×25 mm

Protection Grade:IP20

Certification:CE

Working Temperature:‑10℃ ~ +60℃,non‑condensing

Storage Temperature:‑40℃ ~ +85℃

Humidity:5%‑95% non‑condensing

Application:Power plant,petrochemical,papermaking industry,collect field switch status,relay contact signal,complete digital signal acquisition for DCS control system,system overhaul and spare‑part replacement.

Product Details

57310001‑KN,type DSDI110,is S100 series 16‑channel digital input module for ABB Advant MasterPiece DCS system.

It collects 24VDC field switch and relay contact signals,transmits status data to controller via rack backplane bus. Each channel is equipped with LED indicator for signal status checking. Channel‑to‑bus isolation improves anti‑interference performance. Module fault will cause partial or all digital input signal loss. Widely used for old‑generation S100 I/O site maintenance.

Note:This is legacy EOL spare component,widely used for process industry spare‑part replacement.
