ABB Bailey PHBDIO4000S100 Termination Base

Feature & Principle

It is a dedicated I/O mounting and termination base for ABB Bailey Infi 90 DCS. It supplies backplane bus interface for pluggable digital I/O modules and centralized terminal blocks for field wiring. It routes field digital signals between on-site sensors, actuators and DCS I/O modules. It adopts rack structure for multi-channel signal integration, supports hot swap of matched I/O cards, and provides reliable signal shielding and anti-interference performance for process control.

Specifications

Model: PHBDIO4000S100 Brand: ABB Bailey Applicable system: Infi 90, Net 90 DCS Type: Digital I/O termination base Mounting: Cabinet rack installation Weight: 1.4 kg Dimension: 152 mm × 254 mm × 178 mm Lifecycle: Discontinued legacy DCS spare Application: Power plant, chemical plant, pulp and paper DCS control cabinet Certification: CE

Components & Diagnostics

Backplane bus circuit, terminal strip assembly, card slot frame, status indicator, metal housing. Common faults: terminal loose contact, backplane bus pin corrosion, poor module insertion connection, signal channel interruption.

Product Brief

PHBDIO4000S100 digital I/O termination base, ABB Bailey Infi 90 DCS spare widely used for old process control cabinet overhaul and replacement.
