ABB REA105 Arc Protection Extension Module

Feature & Principle

It is an expansion module for ABB REA arc protection system, used together with REA101 main relay. It receives optical signal from loop or radial fiber sensor, and executes fast tripping when arc light and overcurrent signal are detected at the same time. It provides 3 RJ45 ports for interconnection between main units and extension modules, expands the protection zones of switchgear. It integrates self-supervision function to monitor power supply and fiber loop health, and supports breaker failure protection to send delayed trip signal for upstream breaker.

Specifications

Model: REA105 Brand: ABB Matching master unit: REA101 Sensor type: Loop / radial fiber sensor Trip outputs: 2 high-speed semiconductor HSO outputs Communication port: 3 × RJ45 Function: Arc light detection, breaker failure protection, self-supervision Installation: Cabinet inner mount for air-insulated switchgear Application: Medium voltage and low voltage switchgear room arc flash protection Certification: CE, IEC 60255

Components & Diagnostics

Fiber signal receiving circuit, high-speed trip output unit, communication interface, status LED indicators, power supervision circuit. Common faults: fiber breakage, communication link loss, trip output failure, power supply abnormality.

Product Brief

REA105 arc protection extension module, ABB REA system arc flash detection spare widely used for MV/LV switchgear overhaul and replacement.
