Allen Bradley 2706-M1D1 Display Terminal

Feature & Principle

It is an old-style MessageView text display terminal from Allen Bradley. It communicates with PLC through Remote I/O protocol, receives message data sent by the controller, and displays equipment running status, alarm prompts and fault text information on the screen. It supports preset message storage, trigger display via PLC bits, simple button operation, widely used on old production lines for on-site status viewing and fault prompting.

Specifications

Model: 2706-M1D1 Brand: Allen Bradley (Rockwell) Series: MessageView Communication: Remote I/O Screen: 2-line text display Power supply: 18~30VDC Mounting: Panel mount Lifecycle: Discontinued legacy spare Application: Old packaging, textile, material handling automation lines Certification: CE, UL

Components & Diagnostics

Main control PCB, LCD screen, membrane button, remote I/O communication circuit, status LED. Common faults: screen no display, communication offline, button failure, screen blurred.

Product Brief

2706-M1D1 message display terminal, Allen Bradley old PLC message panel spare widely used for legacy automation equipment overhaul and replacement.
