APTE-165N-1000-3 Incremental Rotary Encoder Unit

Feature & Principle

Photoelectric incremental rotary encoder, generates A/B/Z quadrature pulse signals according to shaft rotation, transmits position and speed feedback signal to controller for closed-loop motion control.

Specifications

Model: APTE-165N-1000-3 Brand: APTE Resolution: 1000 PPR Shaft: Solid shaft Output: Line driver 5V Supply: 5V DC Protection: IP54 Certification: CE

Components & Diagnostics

Optical code disc, photoelectric receiving chip, signal processing board, shaft bearing and cable connector. Common faults: pulse loss, phase signal disorder, no Z marker pulse output.

Product Brief

APTE-165N-1000-3 encoder, APTE incremental rotary encoder spare for servo motor, CNC spindle and packaging machinery speed monitoring.
