B&R 4PP420.0571‑K05 PP420 Power Panel

Technical Specifications

Model:4PP420.0571‑K05

Brand:B&R

Product Type:PP420 Power Panel Custom Membrane Variant Integrated HMI‑PLC Controller

Applicable System:B&R System2005 automation platform, packaging, textile and special‑purpose machinery

Display:5.7‑inch color TFT‑LCD,320×240 QVGA resolution,CCFL backlight, integrated analog resistive touch screen

Key array:Factory custom‑designed membrane keypad layout for dedicated machine operation, supports replaceable key‑label strips

Processor:Geode LX800 500 MHz embedded x86 compatible CPU,MMX instruction set,hardware watchdog integrated,fanless passive cooling

Memory:128 MB SDRAM,512 KB lithium‑battery‑backed SRAM,external replaceable lithium backup battery for RTC and SRAM retention

Expansion resource:1×aPCI internal expansion slot for optional communication modules,1×CompactFlash Type‑I slot for project backup and process‑data logging

Communication interfaces:1×10/100Mbps Ethernet,1×RS232 DSUB‑9 connector,2×USB 1.1 host ports; expand PROFIBUS‑DP / CAN‑bus / RS485 via aPCI add‑on board

Power supply:18‑30VDC DC input,nominal 24VDC; 0TB103.9 screw‑clamp or 0TB103.91 cage‑clamp terminal block must be ordered separately

Indicator LED:Power, CompactFlash status LED onboard

Installation:Cabinet front‑panel cut‑out mounting

Dimension:212mm156mm76mm

Weight:1.82kg(without aPCI module)

Degree of protection:Front‑side IP65, rear‑side IP20

Certification:CE, cULus industrial control equipment certification

Working temperature:0℃ ~ +50℃

Storage temperature:‑20℃ ~ +70℃

Relative humidity:5‑95% non‑condensing

Built‑in function:Independent local PLC program execution,combined touch‑screen and custom membrane‑key operation mode,graphic process‑data visualization,on‑site recipe and parameter modification,fault‑alarm message output,aPCI‑based multi‑field‑bus expansion modules,CompactFlash‑card supported project backup and data logging,Ethernet and serial interfaces realize data exchange with upper‑level host and field peripheral devices.

Product Brief

4PP420.0571‑K05 is B&R EOL discontinued PP420 series custom‑variant all‑in‑one Power Panel for System2005 automation platform. This unit integrates embedded PLC controller, resistive touch HMI and factory‑custom membrane keypad into compact metal cabinet‑mount housing, runs complete machine automation logic without external host CPU unit.

5.7‑inch QVGA color TFT‑LCD delivers clear display for process values,production recipes and equipment fault alarms. Combined resistive touch screen and factory‑custom membrane keys realize convenient dedicated local manual operation. Geode LX800 500MHz processor provides reliable real‑time control performance for medium‑complex automation tasks.

Built‑in aPCI expansion slot allows installing optional communication boards to expand PROFIBUS‑DP,CAN‑bus or RS485 field‑bus interfaces according to site requirements. CompactFlash Type‑I slot supports reliable program backup and process‑data recording. Front‑side IP65 aluminum housing meets dust‑proof and splash‑proof cabinet‑mount installation requirements.

This is legacy EOL spare part widely deployed on old‑generation special‑purpose packaging and textile equipment. Please confirm System2005 project compatibility,custom keypad layout matching and 0TB103‑series terminal‑block availability before purchase. Strict ESD anti‑static protection shall be followed during installation.
