B&R 4PP480.1505-K07 Power Panel HMI Unit

Module Feature

4PP480.1505-K07 belongs to B&R Power Panel series all-in-one HMI and PLC controller. It integrates touch display,CPU,real-time control and communication interfaces in one unit. Support X2X backplane,multiple industrial communication protocols including Ethernet,RS485. Designed for machine builder,packaging,plastic and general factory automation.

Working principle

The embedded CPU runs PLC control program while touch screen provides human-machine interface. Touch operation inputs command; screen displays real-time machine status,alarm and parameter values. Data exchange with remote I/O and other automation devices via industrial bus.

Onboard components

TFT touch display panel,embedded CPU board,flash memory,RAM,communication interface chips,status LED,metal front frame.

LED indicators

Power LED,run LED,fault LED,communication activity LED.

Hardware self-diagnosis

Power monitoring,CPU watchdog,memory check,touch panel self-test,communication link diagnosis,temperature monitoring.

Programming software

Automation Studio,used for PLC programming,HMI screen design,fault log read and parameter download/upload.

Electrical & Process Parameters

Model:4PP480.1505-K07 Brand:B&R Device type:Power Panel Integrated HMI & PLC Display:Color TFT touch screen Power supply:24VDC Communication:Ethernet,X2X,RS485 Cooling:Natural convection cooling Protection:Over temperature,over voltage,reverse polarity protection

Mechanical & Structure

Mounting:Panel cutout mounting Protection class:IP65 front panel Housing:Aluminum front frame,plastic rear housing

Environmental

Operating temperature:0℃ ~ +50℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,UL compliant Status: B&R original all-in-one Power Panel for machinery automation control

Installation

Follow strict ESD safety procedure before handling.Fit unit into cabinet panel cutout and lock with mounting clips.Connect 24VDC power and communication cables.Download project via Automation Studio before commissioning.

Interface

Ethernet port,X2X interface,serial port,24VDC power terminal.

Diagnostic

Touch unresponsive:touch panel damage or wiring fault. Boot fail:corrupted project or power issue. Communication drop:wrong network setting or cable failure.

Product Brief

B&R 4PP480.1505-K07 Power Panel integrated touch HMI and PLC controller,24VDC supply,IP65 front panel,used as machine operating terminal for packaging and production line automation.
