Bently Nevada 47134-1338-139114 Probe Extension Cable Unit

Module Feature

47134-1338-139114 belongs to Bently Nevada 3300 eddy current vibration sensor accessory cable.

It is factory calibrated coaxial extension cable, matched with 3300 series proximity probe and proximitor. Special low-loss RF coaxial wire, double shielded construction to resist EMC interference. Both ends pre-assembled with standard Bently 4-pin connectors, fixed calibrated length, capacitance matched to ensure linear vibration measurement range. It transmits high-frequency eddy current signal between probe and proximitor, widely used in turbomachinery monitoring cabinet for steam turbine, gas turbine, centrifugal compressor and large pump.

Working principle

The cable transmits high frequency RF excitation signal from proximitor to eddy current probe.

It also sends the probe’s reflected impedance signal back to proximitor module. The cable capacitance and impedance must keep consistent; otherwise it will cause gap voltage drift and wrong vibration reading. Double shield layer reduces electromagnetic interference from variable frequency drives and high power equipment.

Onboard components

Low capacitance coaxial core wire, insulation dielectric, inner shield, outer braided shield, outer jacket, molded sealed 4-pin connectors, strain relief boot.

LED indicators

Not applicable, passive cable assembly without electronic indicator. Cable health is judged by 3500 rack channel diagnostic.

Hardware self‑diagnosis

No independent self-diagnosis. The 3500 monitor module can detect cable open circuit, short circuit and gap voltage out of range.

Programming software

System 1, used for vibration channel configuration, gap setting and vibration trend viewing.

Electrical & Process Parameters

Model:47134-1338-139114 Brand:Bently Nevada Device type:Calibrated proximitor extension coaxial cable Function:Signal transmission between eddy current probe and proximitor module for shaft vibration monitoring

Mechanical & Structure

Mounting:Cabinet and field cable tray routing, fixed by cable clamps Protection class:IP65 for connectors (properly mated) Housing:TPU / ETFE high temperature resistant outer jacket

Environmental

Operating temperature:-50℃ ~ +180℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing

Certification:CE, ATEX, IECEx

Status:Original Bently Nevada turbomachinery vibration spare

Installation

Avoid bending cable below minimum bend radius, do not splice or cut calibrated cable.

Route separately away from high voltage power cable, lock connector threads tightly, install cable strain relief.

Interface

Bently standard 4-pin male / female connector for probe and proximitor.

Diagnostic

Gap voltage drift: Cable damaged, connector loose, or wrong length/capacitance cable used. Channel fault alarm: Cable open, short circuit or connector pin corrosion. Vibration noisy signal: Shield broken or improper single-point grounding.

Product Brief

Bently Nevada 47134-1338-139114 extension cable, calibrated coaxial spare cable for 3300 eddy current vibration probe and 3500 turbomachinery monitoring system replacement.
