Eaton 396RVP32070825 Cartridge Pressure Reducing Valve Unit

Module Feature

396RVP32070825 belongs to Eaton RVP screw-in cartridge pressure reducing valve series. It is a direct acting cartridge type valve, designed to supply a constant preset reduced pressure to secondary hydraulic circuits regardless of inlet pressure fluctuation. Pressure can be adjusted via built-in adjustment screw. Compact cartridge construction for manifold mounting, saves installation space. The valve maintains stable outlet pressure to protect downstream hydraulic actuators and sensitive components. Widely used for machine tools, material handling machinery and general industrial hydraulic power units.

Working principle

Inlet hydraulic oil enters the valve. Internal spool senses outlet pressure. If outlet pressure exceeds set value, spool shifts to throttle inlet flow and limit pressure. When outlet pressure drops below setting, spool opens to replenish pressure, maintaining stable reduced pressure for secondary loop.

Onboard components

Hardened valve spool, valve sleeve, pressure adjusting spring, pressure adjustment screw, sealing O-rings, threaded cartridge body.

LED indicators

No built-in LED indicators.

Hardware self-diagnosis

Visual inspection of external oil leakage, test pressure regulation performance, check spool sticking, measure pressure stability at outlet port.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:396RVP32070825 Brand:Eaton Device type:RVP Screw-in Cartridge Pressure Reducing Valve Mount type:Cartridge manifold mount Adjustment style:Screw adjustable Compatible fluid:Mineral hydraulic oil Cooling:Natural convection cooling Protection:O-ring seal prevents external oil leakage

Mechanical & Structure

Mounting:Manifold cartridge installation Protection class:IP65 after assembly Housing:High strength alloy steel cartridge body

Environmental

Operating temperature:-20℃ ~ +60℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status: Eaton original cartridge pressure reducing valve for industrial hydraulic sub-circuit pressure stabilization

Installation

Follow strict hydraulic safety procedure before handling.Screw cartridge valve into standard manifold cavity and torque to specification.Connect main hydraulic lines, adjust outlet pressure via adjustment screw, test pressure stability before full load commissioning.

Interface

Cartridge external thread, internal hydraulic flow ports, pressure adjustment screw interface.

Diagnostic

Cannot build outlet pressure:contamination stuck spool or incorrect adjustment. Pressure unstable:spring fatigue or fluid contamination. External oil leakage:damaged O-ring seal.

Product Brief

Eaton 396RVP32070825 RVP series screw-in cartridge pressure reducing valve, manifold mount, adjustable outlet pressure,for secondary circuit pressure stabilization in industrial hydraulic systems.
