Eaton RFT9739D4SUAEZ Variable Frequency Drive Unit

Module Feature

RFT9739D4SUAEZ belongs to Eaton RFT heavy-duty variable frequency drive series. It adopts high-performance IGBT power module, supporting V/F control and sensorless vector control. Built-in EMC filter suppresses electromagnetic interference; integrated dynamic braking circuit handles regenerative energy during rapid deceleration. Digital control board supports multiple analog and digital I/O signals, and standard Modbus RTU communication interface for PLC network connection. The metal enclosure with built-in cooling fan is designed for continuous heavy-load operation. Widely applied in mining equipment, material handling conveyors, water pumps, industrial fans and other heavy-duty industrial motor speed control occasions.

Working principle

AC mains power is rectified into DC voltage by rectifier bridge. IGBT inverter converts DC voltage to AC with adjustable frequency and voltage. By changing output frequency to adjust motor rotating speed. When motor decelerates, regenerative energy flows back to DC bus, and braking resistor consumes excess energy to prevent overvoltage trip.

Onboard components

Input rectifier module, IGBT power module, DC bus capacitor, dynamic braking circuit, main control PCB, digital/analog I/O terminal block, cooling fan, status indicator panel, EMC filter.

LED indicators

Power LED, run LED, fault alarm LED.

Hardware self-diagnosis

Overvoltage, undervoltage, overcurrent, over-temperature, short circuit, ground fault detection, records fault code and historical operation data.

Programming software

Eaton PC software for parameter backup, real-time monitoring and firmware upgrade.

Electrical & Process Parameters

Model:RFT9739D4SUAEZ Brand:Eaton Device type:RFT Series Heavy Duty 3-phase Variable Frequency Drive Control mode:V/F, Sensorless vector control Communication:Modbus RTU Built-in accessory:EMC filter, dynamic braking circuit Cooling:Forced air cooling Protection:Overcurrent, overvoltage, undervoltage, over temperature, short circuit, earth fault

Mechanical & Structure

Mounting:Panel mount inside control cabinet Protection class:IP20 Housing:Metal painted enclosure

Environmental

Operating temperature:-10℃ ~ +50℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,UL compliant Status: Eaton original heavy-duty VFD for industrial motor variable speed control

Installation

Follow strict ESD and high voltage safety procedure before handling.Mount the drive vertically in control cabinet and reserve ventilation space.Connect main power cable and motor cable to terminals, set motor parameters according to motor nameplate before commissioning.

Interface

Power input terminals, motor output terminals,digital/analog I/O terminals,Modbus communication port,keypad interface.

Diagnostic

Drive trip on startup:motor cable short circuit, wrong motor parameters or insulation damage. Over temperature fault:cooling fan failure or insufficient cabinet ventilation. No communication:incorrect Modbus address or wiring error.

Product Brief

Eaton RFT9739D4SUAEZ RFT series heavy-duty variable frequency drive,3-phase,built-in EMC filter and braking circuit,IP20 panel mount,for industrial fan,pump and heavy machinery speed regulation.
