This optical incremental encoder uses code disc and photoelectric receiving components. It generates A/B quadrature pulses and Z index pulse, which are sent to PLC or servo drive to calculate rotation speed, direction and index position. Compact housing structure resists vibration, and it provides stable pulse signal for closed-loop motion control.

Certification: CE

Code disc, photoelectric receiver board, signal processing circuit, bearing assembly, connector and metal housing. Common faults: pulse missing, zero mark failure, signal attenuation, bearing noise and wiring short circuit.
