Emerson IC695ALG112CA Analog Input Module

Feature & Principle

It is Emerson PACSystems RX3i series 12-channel isolated analog input module, CA represents conformal coated version. Each channel can be independently configured for current or voltage signals, converts analog signals from field transmitters into digital data for PLC processing. It supports channel isolation and built-in channel fault diagnosis, with hot-swap function, can be replaced without powering down the rack. Conformal coating protects circuit board against moisture, dust and corrosive gas, suitable for offshore, mining and chemical harsh industrial environments.

Specifications

Model: IC695ALG112CA Brand: Emerson (GE Fanuc) Series: PACSystems RX3i Channel: 12 isolated channels Signal range: 4-20mA, 0-20mA, ±20mA, ±10V, 0-10V, ±5V, 0-5V, 1-5V Resolution: 16 bit ADC Filter: Multiple filter frequency optional Coating: Conformal coating Installation: RX3i universal backplane rack Terminal block: Sold separately Application: Petrochemical, water treatment, marine, mining DCS and control cabinet Certification: CE, UL, ATEX, DNV

Components & Diagnostics

ADC conversion chip, isolation circuit, backplane gold finger, terminal circuit, status LED, protective conformal coating. Common faults: signal drift, no signal input, channel fault alarm, module cannot be identified.

Product Brief

IC695ALG112CA analog input module, Emerson RX3i conformal coated analog acquisition spare widely used for process control cabinet overhaul and replacement.
